电芯

  • 21700 4000mAh 锂离子电池
  • 21700 4000mAh 锂离子电池
  • 21700 4000mAh 锂离子电池
21700 4000mAh 锂离子电池 21700 4000mAh 锂离子电池 21700 4000mAh 锂离子电池

21700 4000mAh 锂离子电池

  • 型号:21700 4000mAh
  • 尺寸: 21.5×70.5mm
  • 重量: 70g
  • 容量: 4000mAh
  • 产品描述: 21700 4000mAh-li-ion-battery-pack
  • 在线订购   邮箱L

No.

Item

General Parameter

Remark

1

Charge Voltage

4.20±0.02V

Charge mode:CC/CV

2

Nominal Voltage

3.7V


3

Capacity

Nominal

4000mAh

Standard discharge0.2C C5A,2.75V) after Standard charge

Minimum

3900mAh

4

Cycle Life

500 Times

One cycle refer to one charge period and then one discharge period.

Test condition:

Charge: 0.2C to 4.2V

Discharge: 0.2C to 2.75V

The cycle life is the cycle times when the discharge capacity is about 70% of the rated capacity.

5

Internal Impedance

35

After standard charging, measure the internal resistance with AC1KHz

6

Standard  Charge

0.2C5A

Constant Current 0.2C5A

Constant Voltage 4.2V

0.01 C5A cut-off

7

Max Continuous Charge

1.0C5A


8

Standard Discharge

1.0C5A


9

Max Continuous Discharge

5.0C5A
